RangeAGM L-seriesA40

A40

AGM-L0 · AGM Start-Stop Battery · 12V40Ah

Download data sheet

PDF · 1.3 MB · English · V1.0

Capacity, 20 h
40Ah
Cold cranking, −18 °C
420A
Reserve capacity
60min
Approx. weight
12.5kg
Case L × W × H
175×175×190mm

Same family

Publication No. LB-AGM-L0-PD-EN-V1.0-20250103

Address on the sticker https://hyperbattery.net/m/A40

Values are subject to variation of +/- 5% in normal manufacturing processes.

Hyper A40 battery, factory render

    Characteristics

    As printed on the data sheet.
    ItemSpecifications
    Nominal Voltage12V
    Nominal Capacity (20HR)40Ah
    Reserve Capacity60min
    Cold Cranking Amps@0°F (-18°C)420A
    Dimension
    Length175mm (6.89inches)
    Width175mm (6.89inches)
    Height190mm (7.48inches)
    Approx Weight12.5kg (27.6lbs)
    Terminal1
    Cell layout0
    Hold-DownB13
    CaseBlack-PP Material
    CoverBlack-PP Material
    HandleNONE

    Applications · General features

    Applications

    • Car with start-stop system
    • EV/HEV
    • Engine start

    General features

    • Maximum CCA and life
    • Valve regulated technology
    • Advanced Absorbed Glass Mat (AGM) technology
    • Top-level safety - absolutely no free acid
    • 2x Faster Charge Acceptance than conventional starter batteries
    • 3x higher cycle life than conventional starter batteries
    • Suit for working in partial state of charge operations (PSoC)
    • OE quality certification

    Drawings

    Factory drawings, dimensions in mm.
    Terminals, A40
    Terminals
    Case outline, A40
    Case outline
