RangeAGM L-seriesA50

A50

AGM-L1 · AGM Start-Stop Battery · 12V50Ah

Download data sheet

PDF · 2.2 MB · English · V1.0

Capacity, 20 h
50Ah
Cold cranking, −18 °C
570A
Reserve capacity
80min
Approx. weight
15.1kg
Case L × W × H
207×175×190mm

Same family

Publication No. LB-AGM-L1-PD-EN-V1.0-20250103

Address on the sticker https://hyperbattery.net/m/A50

Values are subject to variation of +/- 5% in normal manufacturing processes.

Hyper A50 battery, factory render

    Characteristics

    As printed on the data sheet.
    ItemSpecifications
    Nominal Voltage12V
    Nominal Capacity (20HR)50Ah
    Reserve Capacity80min
    Cold Cranking Amps@0°F (-18°C)570A
    Dimension
    Length207mm (8.15inches)
    Width175mm (6.89inches)
    Height190mm (7.48inches)
    Approx Weight15.1kg (33.3lbs)
    Terminal1
    Cell layout0
    Hold-DownB13
    CaseBlack-PP Material
    CoverBlack-PP Material
    HandleTS2

    Applications · General features

    Applications

    • Car with start-stop system
    • EV/HEV
    • Engine start

    General features

    • Maximum CCA and life
    • Valve regulated technology
    • Advanced Absorbed Glass Mat (AGM) technology
    • Top-level safety - absolutely no free acid
    • 2x Faster Charge Acceptance than conventional starter batteries
    • 3x higher cycle life than conventional starter batteries
    • Suit for working in partial state of charge operations (PSoC)
    • OE quality certification

    Drawings

    Factory drawings, dimensions in mm.
    Terminals, A50
    Terminals
    Case outline, A50
    Case outline
