RangeAGM L-seriesA70

A70

AGM-L3 · AGM Start-Stop Battery · 12V70Ah

Download data sheet

PDF · 3.0 MB · English · V1.1

Capacity, 20 h
70Ah
Cold cranking, −18 °C
760A
Reserve capacity
120min
Approx. weight
20.5kg
Case L × W × H
278×175×190mm

Same family

Publication No. LB-AGM-L3-PD-EN-V1.1-20251210

Address on the sticker https://hyperbattery.net/m/A70

Values are subject to variation of +/- 5% in normal manufacturing processes.

Hyper A70 battery, factory render

    Characteristics

    As printed on the data sheet.
    ItemSpecifications
    Nominal Voltage12V
    Nominal Capacity (20HR)70Ah
    Reserve Capacity120min
    Cold Cranking Amps@0°F (-18°C)760A
    Dimension
    Length278mm (10.9inches)
    Width175mm (6.89inches)
    Height190mm (7.48inches)
    Approx Weight20.5kg (45.2lbs)
    Terminal1
    Cell layout0
    Hold-DownB13
    CaseBlack-PP Material
    CoverBlack-PP Material
    HandleTS6

    Applications · General features

    Applications

    • Car with start-stop system
    • EV/HEV
    • Engine start

    General features

    • Maximum CCA and life
    • Valve regulated technology
    • Advanced Absorbed Glass Mat (AGM) technology
    • Top-level safety - absolutely no free acid
    • 2x Faster Charge Acceptance than conventional starter batteries
    • 3x higher cycle life than conventional starter batteries
    • Suit for working in partial state of charge operations (PSoC)
    • OE quality certification

    Drawings

    Factory drawings, dimensions in mm.
    Terminals, A70
    Terminals
    Case outline, A70
    Case outline
