RangeAGM L-seriesA80

A80

AGM-L4 · AGM Start-Stop Battery · 12V80Ah

Download data sheet

PDF · 2.6 MB · English · V1.0

Capacity, 20 h
80Ah
Cold cranking, −18 °C
800A
Reserve capacity
140min
Approx. weight
23.3kg
Case L × W × H
315×175×190mm

Same family

Publication No. LB-AGM-L4-PD-EN-V1.0-20250103

Address on the sticker https://hyperbattery.net/m/A80

Values are subject to variation of +/- 5% in normal manufacturing processes.

Hyper A80 battery, factory render

    Characteristics

    As printed on the data sheet.
    ItemSpecifications
    Nominal Voltage12V
    Nominal Capacity (20HR)80Ah
    Reserve Capacity140min
    Cold Cranking Amps@0°F (-18°C)800A
    Dimension
    Length315mm (12.4inches)
    Width175mm (6.89inches)
    Height190mm (7.48inches)
    Approx Weight23.3kg (51.4lbs)
    Terminal1
    Cell layout0
    Hold-DownB13
    CaseBlack-PP Material
    CoverBlack-PP Material
    HandleTS6

    Applications · General features

    Applications

    • Car with start-stop system
    • EV/HEV
    • Engine start

    General features

    • Maximum CCA and life
    • Valve regulated technology
    • Advanced Absorbed Glass Mat (AGM) technology
    • Top-level safety - absolutely no free acid
    • 2x Faster Charge Acceptance than conventional starter batteries
    • 3x higher cycle life than conventional starter batteries
    • Suit for working in partial state of charge operations (PSoC)
    • OE quality certification

    Drawings

    Factory drawings, dimensions in mm.
    Terminals, A80
    Terminals
    Case outline, A80
    Case outline
