RangeAuxiliaryAUX 14J

AUX 14J

JB14-4 · Auxiliary Battery · 12V14Ah

Download data sheet

PDF · 1.9 MB · English · V1.0

Capacity, 20 h
14Ah
Cold cranking, −18 °C
200A
Reserve capacity
not on the sheet
Approx. weight
4.62kg
Case L × W × H
150×87×145mm

Same family

Publication No. LB-JB14-4-PD-EN-V1.0-20250103

Address on the sticker https://hyperbattery.net/m/AUX14J

Values are subject to variation of +/- 5% in normal manufacturing processes.

AUX 14J — Outline drawing

    Outline drawing shown: the factory render of this model carries third-party marks.

    Characteristics

    As printed on the data sheet.
    ItemSpecifications
    Nominal Voltage12V
    Nominal Capacity (20HR)14Ah
    Cold Cranking Amps@0°F (-18°C)200A
    Dimension
    Length150mm (5.91inches)
    Width87mm (3.43inches)
    Height145mm (5.71inches)
    Approx Weight4.62kg (10.2lbs)
    TerminalK
    Cell layout1
    Hold-DownB0
    CaseBlack-PP Material
    CoverBlack-PP Material
    Handle/

    Applications · General features

    Applications

    • High-end car auxiliary
    • Safety assistant

    General features

    • VRLA technology with long life
    • Modified PP material case and cover, with high strength and impact resistance
    • Top-level safety - absolutely no free acid
    • Absorb the instantaneous overvoltage in the vehicle circuit, protect the vehicle circuit from damage
    • Uninterruptible power supply for safety components and escort for safety during driving
    • OE quality certification

    Drawings

    Factory drawings, dimensions in mm.
    Terminals, AUX 14J
    Terminals
    Case outline, AUX 14J
    Case outline
