RangeEFB L-seriesE60

E60

EFB-L2 · EFB Start-Stop Battery · 12V60Ah

Download data sheet

PDF · 2.2 MB · English · V1.1

Capacity, 20 h
60Ah
Cold cranking, −18 °C
640A
Reserve capacity
100min
Approx. weight
17.5kg
Case L × W × H
242×175×190mm

Same family

Publication No. LB-EFB-L2-PD-EN-V1.1-20250709

Address on the sticker https://hyperbattery.net/m/E60

Values are subject to variation of +/- 5% in normal manufacturing processes.

Hyper E60 battery, factory render

    Characteristics

    As printed on the data sheet.
    ItemSpecifications
    Nominal Voltage12V
    Nominal Capacity (20HR)60Ah
    Reserve Capacity100min
    Cold Cranking Amps@0°F (-18°C)640A
    Dimension
    Length242mm (9.53inches)
    Width175mm (6.89inches)
    Height190mm (7.48inches)
    Approx Weight17.5kg (38.6lbs)
    Terminal1
    Cell layout0
    Hold-DownB13
    CaseBlack-PP Material
    CoverBlack-PP Material
    HandleTS2

    Applications · General features

    Applications

    • Car with start-stop system
    • EV/HEV
    • Engine start

    General features

    • High capacity and high CCA
    • 2x Faster Charge Acceptance than conventional starter batteries
    • 2x Higher Cycle Life than conventional starter batteries
    • Strong alloy grids for rugged durability and improved tolerance in extreme temperature conditions
    • OE quality certification

    Drawings

    Factory drawings, dimensions in mm.
    Terminals, E60
    Terminals
    Case outline, E60
    Case outline
